Pass & Seymour CS15AC1BK
Pass & Seymour Commercial Toggle-Grade Switch, 120/277 VAC, 15 A, 1 Pole, Silver Alloy Contact, 1500 V Dielectric Strength, Side Wire Terminal, -40 to 115 deg C, Nylon Housing Material, Black, Dimensions: 1.32 in W x 1.07 in D x 3.28 in H
| Switch Type | : | Toggle |
| Voltage Rating | : | 120/277 V |
| Function Type | : | Single Pole |
| Current Rating | : | 15 A |
| Color | : | Black |
| Dielectric Strength | : | 1500 V |
| Number of Poles | : | 1 |
| Contact Material | : | Silver Alloy |
| Terminal Type | : | Side Wire |
| Temperature Rating | : | -40 to 115 deg C |
| Housing Material | : | Nylon |
| Dimensions | : | 1.32 in W x 1.07 in D x 3.28 in H |
- One-piece brass alloy contact arm for reliable electrical performance
- One-piece steel strap with integral ground is plated for corrosion resistance
- High strength thermoplastic polycarbonate toggle resists breaking and chipping under heavy abuse
- Heavy-duty toggle bumpers for smooth and quiet operation
- Back body made of glass-reinforced nylon, locking support provides resistance to face and back body separation
- Available with side wire or external screw-pressure-plate back and side wire models capable of accepting #14 to #10 AWG copper or copper-clad wire
- Cam designed for fast make with positive break action to minimize arcing and prolong switch life
- Oversized silver alloy contacts for longer dependable switch life
- Tri-drive terminal and mounting screws
